Rated voltage
U0/U 300/500V
U0/U 300/500V
Fixed installation: 6D (D = cable diameter)
Mobile installation: 13D (D = cable diameter)
Fixed installation: -10℃ ~ +70℃
Mobile installation: -5℃ ~ +70℃
Passed IEC 60332.1 test
Cable data
|
Product Code |
cross section mm² |
Chip count |
Approximate outer diameter (mm) |
Approximate weight (kg/km) |
|
B0435102339001422BK |
0.75（flat） |
2 |
(3.9±0.4)×(6.2±0.4) |
39 |
|
B0335102013001422BK |
0.75 |
2 |
6.3±0.4 |
52 |
|
B0435102340001422BK |
1.0（flat） |
2 |
(4.1±0.4)×(6.6±0.4) |
46 |
|
B0335102014001422BK |
1.0 |
2 |
6.7±0.4 |
59 |
|
B0335102016001422BK |
1.5 |
2 |
7.7±0.4 |
83 |
|
B0335102018001422BK |
2.5 |
2 |
9.5±0.4 |
123 |
|
B0335103013001422BK |
0.75 |
3 |
6.7±0.4 |
60 |
|
B0335103014001422BK |
1.0 |
3 |
7.1 ±0.4 |
69 |
|
B0335103016001422BK |
1.5 |
3 |
8.4±0.6 |
102 |
|
B0335103018001422BK |
2.5 |
3 |
10.1 ±0.6 |
152 |
|
B0335104013001422BK |
0.75 |
4 |
7.3±0.4 |
74 |
|
B0335104014001422BK |
1.0 |
4 |
7.9±0.4 |
91 |
|
B0335104016001422BK |
1.5 |
4 |
9.4±0.6 |
129 |
|
B0335104018001422BK |
2.5 |
4 |
11.3±0.6 |
199 |
|
B0335105013001422BK |
0.75 |
5 |
8.1 ±0.6 |
94 |
|
B0335105014001422BK |
1.0 |
5 |
8.5±0.6 |
111 |
|
B0335105016001422BK |
1.5 |
5 |
10.4±0.6 |
160 |
|
B0335105018001422BK |
2.5 |
5 |
12.5±0.6 |
248 |
