Rated voltage
U0U 300/500V
U0U 300/500V
Fixed installation: 6D (cable outer diameter)
Mobile installation: 13D (cable outer diameter)
Fixed installation: -10℃ ~ +70℃
Mobile installation: -5℃ ~ +70℃
Passed IEC 60332.1 test
Oil resistance, cold resistance, acid and alkali resistance, solvent resistance, etc. (optional)
Cable data
|
Product Code |
Cross section (mm2) |
Chip count |
Approximate outer diameter (mm) |
Approximate weight (kg/km) |
|
B2235102012011406BK |
0.5 |
2 |
8.0±0.6 |
71 |
|
B2235102013011406BK |
0.75 |
2 |
8.4±0.6 |
80 |
|
B2235102014011406BK |
1 |
2 |
8.8±0.6 |
89 |
|
B2235102016011406BK |
1.5 |
2 |
10.0±0.6 |
120 |
|
B2235102018011406BK |
2.5 |
2 |
11.5±0.6 |
163 |
|
B2235103012011406BK |
0.5 |
3 |
8.3±0.6 |
76 |
|
B2235103013011406BK |
0.75 |
3 |
8.8±0.6 |
89 |
|
B2235103014011406BK |
1 |
3 |
9.4±0.6 |
105 |
|
B2235103016011406BK |
1.5 |
3 |
10.4±0.6 |
138 |
|
B2235103018011406BK |
2.5 |
3 |
12.1 ±0.6 |
194 |
|
B2235104012011406BK |
0.5 |
4 |
8.9±0.6 |
90 |
|
B2235104013011406BK |
0.75 |
4 |
9.6±0.6 |
112 |
|
B2235104014011406BK |
1 |
4 |
10.0±0.6 |
126 |
|
B2235104016011406BK |
1.5 |
4 |
11.4±0.6 |
169 |
|
B2235104018011406BK |
2.5 |
4 |
13.4±0.6 |
251 |
|
B2235105012011406BK |
0.5 |
5 |
9.7±0.6 |
110 |
|
B2235105013011406BK |
0.75 |
5 |
10.3±0.6 |
129 |
|
B2235105014011406BK |
1 |
5 |
10.9±0.6 |
155 |
|
B2235105016011406BK |
1.5 |
5 |
12.7±0.6 |
212 |
|
B2235105018011406BK |
2.5 |
5 |
14.7±0.8 |
309 |
|
B2235106012011406BK |
0.5 |
6 |
10.3±0.6 |
126 |
|
B2235106013011406BK |
0.75 |
6 |
11.2±0.6 |
154 |
|
B2235106014011406BK |
1 |
6 |
11.7±0.6 |
176 |
|
B2235106016011406BK |
1.5 |
6 |
13.6±0.6 |
245 |
|
B2235106018011406BK |
2.5 |
6 |
16.1 ±0.8 |
361 |
|
B2235107012011406BK |
0.5 |
7 |
10.5±0.6 |
146 |
|
B2235107013011406BK |
0.75 |
7 |
11.4±0.6 |
178 |
|
B2235107014011406BK |
1 |
7 |
12.1 ±0.6 |
209 |
|
B2235107016011406BK |
1.5 |
7 |
13.8±0.6 |
282 |
|
B2235107018011406BK |
2.5 |
7 |
16.3±0.8 |
415 |
|
B2235112012011406BK |
0.5 |
12 |
14.1 ±0.8 |
216 |
|
B2235112013011406BK |
0.75 |
12 |
15.0±0.8 |
261 |
|
B2235112014011406BK |
1 |
12 |
15.9±0.8 |
310 |
|
B2235112016011406BK |
1.5 |
12 |
18.4±0.8 |
423 |
|
B2235112018011406BK |
2.5 |
12 |
21.7±1.0 |
638 |
|
B2235118012011406BK |
0.5 |
18 |
16.1 ±0.8 |
291 |
|
B2235118013011406BK |
0.75 |
18 |
17.5±0.8 |
371 |
|
B2235118014011406BK |
1 |
18 |
18.4±0.8 |
432 |
|
B2235118016011406BK |
1.5 |
18 |
21.3±1.0 |
606 |
|
B2235118018011406BK |
2.5 |
18 |
25.4±1.2 |
929 |
|
B2235127012011406BK |
0.5 |
27 |
19.1 ±0.8 |
416 |
|
B2235127013011406BK |
0.75 |
27 |
20.8±1.0 |
531 |
|
B2235127014011406BK |
1 |
27 |
21.9±1.0 |
622 |
|
B2235127016011406BK |
1.5 |
27 |
25.6±1.2 |
882 |
|
B2235127018011406BK |
2.5 |
27 |
30.5±1.4 |
1344 |
|
B2235136012011406BK |
0.5 |
36 |
21.3±1.0 |
539 |
|
B2235136013011406BK |
0.75 |
36 |
23.0±1.0 |
674 |
|
B2235136014011406BK |
1 |
36 |
24.4±1.0 |
807 |
|
B2235136016011406BK |
1.5 |
36 |
28.7±1.2 |
1155 |
|
B2235136018011406BK |
2.5 |
36 |
34.0±1.4 |
1741 |
|
B2235148012011406BK |
0.5 |
48 |
24.2±1.0 |
695 |
|
B2235148013011406BK |
0.75 |
48 |
26.5±1.2 |
896 |
|
B2235148014011406BK |
1 |
48 |
27.9±1.2 |
1055 |
|
B2235148016011406BK |
1.5 |
48 |
32.8±1.4 |
1506 |
|
B2235148018011406BK |
2.5 |
48 |
38.6±1.6 |
2230 |
|
B2235160012011406BK |
0.5 |
60 |
26.6±1.2 |
864 |
|
B2235160013011406BK |
0.75 |
60 |
28.6±1.2 |
1082 |
|
B2235160014011406BK |
1 |
60 |
30.4±1.4 |
1295 |
|
B2235160016011406BK |
1.5 |
60 |
35.5±1.6 |
1811 |
|
B2235160018011406BK |
2.5 |
60 |
41.7±1.8 |
2703 |
