Rated voltage
U0/U 600/1000V
U0/U 600/1000V
Fixed installation: 20D (cable outer diameter)
Mobile installation: 15D (cable outer diameter)
Fixed installation: -10℃ ~ +70℃
Passed IEC 60332.1 test
Oil resistance, cold resistance, acid and alkali resistance, solvent resistance, etc. (optional)
Cable data
|
Product Code |
Cross section (mm2) |
Chip count |
Approximate outer diameter (mm) |
Approximate weight (kg/km) |
|
T0461101019000125BK |
4RE |
1 |
8.4±0.6 |
105.09 |
|
T0461101020000125BK |
6RE |
1 |
8.9±0.6 |
127.9 |
|
T0462101021000125BK |
10RM |
1 |
10.2±0.6 |
181.59 |
|
T0462101022000125BK |
16RM |
1 |
11.2±0.6 |
245.34 |
|
T0462101023000125BK |
25RM |
1 |
12.9±0.6 |
353.4 |
|
T0462101024000125BK |
35RM |
1 |
14±0.8 |
452.23 |
|
T0462101025000125BK |
50RM |
1 |
15.8±0.8 |
594.91 |
|
T0462101026000125BK |
70RM |
1 |
17.5±0.8 |
802.02 |
|
T0462101027000125BK |
95RM |
1 |
19.8±0.8 |
1074.86 |
|
T0462101028000125BK |
120RM |
1 |
21.3±1 |
1319.22 |
|
T0462101029000125BK |
150RM |
1 |
23.3±1 |
1608.38 |
|
T0462101030000125BK |
185RM |
1 |
25.5±1.2 |
1984.95 |
|
T0462101031000125BK |
240RM |
1 |
28.5±1.2 |
2571.58 |
|
T0462101032000125BK |
300RM |
1 |
31.4±1.4 |
3192.01 |
|
T0461103016000125BK |
1.5RE |
3 |
10.6±0.6 |
143.09 |
|
T0461103018000125BK |
2.5RE |
3 |
11.4±0.6 |
181.61 |
|
T0461103019000125BK |
4RE |
3 |
13.3±0.6 |
257.15 |
|
T0461103020000125BK |
6RE |
3 |
14.3±0.8 |
324.12 |
|
T0462103021000125BK |
10RM |
3 |
17.1 ±0.8 |
485.3 |
|
T0462103022000125BK |
16RM |
3 |
19.3±0.8 |
680.47 |
|
T0461104016000125BK |
1.5RE |
4 |
11.4±0.6 |
170.09 |
|
T0461104018000125BK |
2.5RE |
4 |
12.3±0.6 |
221.53 |
|
T0461104019000125BK |
4RE |
4 |
14.4±0.8 |
314.83 |
|
T0461104020000125BK |
6RE |
4 |
15.5±0.8 |
405.33 |
|
T0462104021000125BK |
10RM |
4 |
18.7±0.8 |
613.54 |
|
T0462104022000125BK |
16RM |
4 |
21.1 ±1 |
862.79 |
|
T0462104505000125BK |
25RM/16RM |
3+1 |
24.2±1 |
1193.38 |
|
T0461105016000125BK |
1.5RE |
5 |
12.2±0.6 |
200.58 |
|
T0461105018000125BK |
2.5RE |
5 |
13.3±0.6 |
259.78 |
|
T0461105019000125BKT |
4RE |
5 |
15.6±0.8 |
379.11 |
|
0461105020000125BK |
6RE |
5 |
16.9±0.8 |
485.57 |
|
T0462105021000125BK |
10RM |
5 |
20.4±1 |
743.12 |
|
T0462105022000125BK |
16RM |
5 |
23.1 ±1 |
1051.5 |
|
T0462105023000125BK |
25RM |
5 |
27.7±1.2 |
1583.52 |
|
T0461107016000125BK |
1.5RE |
7 |
13.1 ±0.6 |
245.28 |
|
T0461107018000125BK |
2.5RE |
7 |
14.3±0.8 |
325.89 |
|
T0461107019000125BK |
4RE |
7 |
16.9±0.8 |
476.53 |
|
T0461107020000125BK |
6RE |
7 |
18.3±0.8 |
621.34 |
|
T0461110016000125BK |
1.5RE |
10 |
16.1 ±0.8 |
341.47 |
|
T0461110018000125BK |
2.5RE |
10 |
17.6±0.8 |
457.46 |
|
T0461112016000125BK |
1.5RE |
12 |
16.5±0.8 |
381.49 |
|
T0461112018000125BK |
2.5RE |
12 |
18.2±0.8 |
516.55 |
|
T0461114016000125BK |
1.5RE |
14 |
17.3±0.8 |
431.53 |
|
T0461114018000125BK |
2.5RE |
14 |
19±0.8 |
587.63 |
|
T0461116016000125BK |
1.5RE |
16 |
18.2±0.8 |
482.64 |
|
T0461116018000125BK |
2.5RE |
16 |
20±0.8 |
659.87 |
|
T0461119016000125BK |
1.5RE |
19 |
19.1 ±0.8 |
551.86 |
|
T0461119018000125BK |
2.5RE |
19 |
21 ±1 |
760.23 |
|
T0461121016000125BK |
1.5RE |
21 |
19.9±0.8 |
606.17 |
|
T0461121018000125BK |
2.5RE |
21 |
22±1 |
835.71 |
|
T0461124016000125BK |
1.5RE |
24 |
22±1 |
690.49 |
|
T0461124018000125BK |
2.5RE |
24 |
24.4±1 |
954.34 |
|
T0461130016000125BK |
1.5RE |
30 |
23.2±1 |
823 |
|
T0461130018000125BK |
2.5RE |
30 |
25.8±1.2 |
1147.06 |
|
T0461140016000125BK |
1.5RE |
40 |
25.9±1.2 |
1061.3 |
|
T0461140018000125BK |
2.5RE |
40 |
28.9±1.2 |
1502.09 |
|
T0461152018000125BK |
2.5RE |
52 |
32.9±1.4 |
1923.7 |
|
T0461161016000125BK |
1.5RE |
61 |
31.3±1.4 |
1575.17 |
|
T0461161018000125BK |
2.5RE |
61 |
35±1.6 |
2239 |
