600V
| conductor | insulation | Maximum conductor resistance（Q/m，20°C，DC） | Compressive strength（VAC，1min） | |||
|---|---|---|---|---|---|---|
| Line gauge （AWG） |
structure | outer diameter （mm） |
nominal thickness（mm） | outer diameter （mm） |
||
|
30 |
7/0.10 |
0.30 |
0.76 |
1.82 |
354 |
2000 |
|
28 |
1/0.32 |
0.32 |
0.76 |
1.90 |
227 |
2000 |
|
28 |
7/0.127 |
0.38 |
0.76 |
1.90 |
223 |
2000 |
|
28 |
7/0.1270S-1 |
0.38 |
0.76 |
2.00 |
239 |
2000 |
|
26 |
1/0.404 |
0.40 |
0.76 |
2.00 |
140 |
2000 |
|
26 |
7/0.16 |
0.48 |
0.76 |
2.00 |
150 |
2000 |
|
26 |
7/0.160S-1 |
0.48 |
0.76 |
2.10 |
150 |
2000 |
|
24 |
1/0.511 |
0.51 |
0.76 |
2.10 |
89.3 |
2000 |
|
24 |
11/0.16 |
0.61 |
0.76 |
2.13 |
87.6 |
2000 |
|
24 |
7/0.200S-1 |
0.60 |
0.76 |
2.25 |
94.2 |
2000 |
|
22 |
1/0.643 |
0.64 |
0.76 |
2.25 |
56.4 |
2000 |
|
22 |
17/0.16 |
0.76 |
0.76 |
2.28 |
55.4 |
2000 |
|
22 |
7/0.2540S-1 |
0.76 |
0.76 |
2.40 |
59.4 |
2000 |
|
20 |
1/0.813 |
0.81 |
0.76 |
2.40 |
35.2 |
2000 |
|
20 |
26/0.16 |
0.94 |
0.76 |
2.46 |
34.6 |
2000 |
|
20 |
7/0.320S-1 |
0.96 |
0.76 |
2.55 |
36.7 |
2000 |
|
18 |
1/1 .024 |
1.02 |
0.76 |
2.65 |
22.2 |
2000 |
|
18 |
41/0.16 |
1.18 |
0.76 |
2.70 |
21.8 |
2000 |
|
18 |
7/0.4040S-1 |
1.21 |
0.76 |
2.80 |
23.2 |
2000 |
|
16 |
1/1 .29 |
1.29 |
0.76 |
2.90 |
14.0 |
2000 |
|
16 |
26/0.254 |
1.56 |
0.76 |
3.08 |
13.7 |
2000 |
|
14 |
1/1 .60 |
1.60 |
0.76 |
3.20 |
8.62 |
2000 |
|
14 |
41/0.254 |
2.03 |
0.76 |
3.55 |
8.61 |
2000 |
|
12 |
65/0.254 |
2.36 |
0.76 |
3.88 |
5.43 |
2000 |
|
11 |
82/0.254 |
2.65 |
0.76 |
4.17 |
4.3 |
2000 |
|
10 |
104/0.254 |
2.99 |
0.76 |
4.51 |
3.41 |
2000 |
|
9 |
94/0.3 |
3.76 |
0.76 |
5.28 |
2.70 |
2000 |
|
8 |
118/0.3 |
4.12 |
1.14 |
6.40 |
2.14 |
2000 |
|
7 |
147/0.3 |
4.73 |
1.14 |
7.01 |
1.70 |
2000 |
|
6 |
189/0.3 |
5.37 |
1.52 |
8.41 |
1.38 |
2000 |
|
4 |
299/0.3 |
6.79 |
1.52 |
9.83 |
0.865 |
2000 |
|
3 |
378/0.3 |
7.62 |
1.52 |
10.66 |
0.686 |
2000 |
|
2 |
475/0.3 |
8.62 |
1.52 |
11.66 |
0.544 |
2500 |
|
1 |
600/0.3 |
10.20 |
2.03 |
14.21 |
0.431 |
2500 |
|
1/0 |
272/0.5 |
10.70 |
2.03 |
14.76 |
0.350 |
2500 |
|
2/0 |
343/0.5 |
12.16 |
2.03 |
16.22 |
0.273 |
2500 |
|
3/0 |
433/0.5 |
13.77 |
2.03 |
17.83 |
0.220 |
2500 |
|
4/0 |
546/0.5 |
15.50 |
2.03 |
19.56 |
0.172 |
2500 |
