conductor stranding
Complies with UL standards: UL758, UL1581, and CSA, C22.2, No. 210.2
Complies with UL standards: UL758, UL1581, and CSA, C22.2, No. 210.2
30V
| conductor | insulation | Maximum conductor resistance （Q/m，20°C，DC） |
Compressive strength（VAC，1min） | ||||||
|---|---|---|---|---|---|---|---|---|---|
| Wire gauge (AWG) | structure | Outer diameter (mm) | nominal thickness（mm） | outer diameter（mm） | |||||
|
36 |
7/0.05 |
0.15 |
0.05 |
0.45 |
- |
- |
- |
1549 |
500 |
|
34 |
7/0.063 |
0.19 |
0.05 |
0.50 |
- |
- |
- |
966 |
500 |
|
32 |
7/0.08 |
0.24 |
0.05 |
0.60 |
- |
- |
- |
596 |
500 |
|
30 |
1/0.254 |
0.25 |
0.05 |
0.65 |
- |
- |
- |
361 |
500 |
|
30 |
7/0.10 |
0.30 |
0.25 |
0.80 |
- |
- |
- |
354 |
500 |
|
28 |
1/0.32 |
0.32 |
0.05 |
0.70 |
- |
- |
- |
227 |
500 |
|
28 |
7/0.127 |
0.38 |
0.25 |
0.88 |
- |
- |
- |
223 |
500 |
|
28 |
7/0.1270S-1 |
0.38 |
0.05 |
0.90 |
- |
- |
- |
239 |
500 |
|
26 |
1/0.404 |
0.40 |
0.05 |
0.90 |
- |
- |
- |
143 |
500 |
|
26 |
7/0.16 |
0.48 |
0.25 |
1.98 |
- |
- |
- |
140 |
500 |
|
26 |
7/0.160S-1 |
0.48 |
0.05 |
1.00 |
- |
- |
- |
150 |
500 |
|
24 |
1/0.511 |
0.51 |
0.05 |
1.00 |
- |
- |
- |
89.3 |
500 |
|
24 |
11/0.16 |
0.61 |
0.25 |
1.11 |
- |
- |
- |
87.6 |
500 |
|
24 |
7/0.200S-1 |
0.60 |
0.05 |
1.10 |
- |
- |
- |
94.2 |
500 |
|
22 |
1/0.643 |
0.64 |
0.05 |
1.15 |
- |
- |
- |
56.4 |
500 |
|
22 |
17/0.16 |
0.76 |
0.25 |
1.26 |
- |
- |
- |
55.4 |
500 |
|
22 |
7/0.2540S-1 |
0.76 |
0.05 |
1.30 |
- |
- |
- |
59.4 |
500 |
|
20 |
26/0.16 |
0.94 |
0.25 |
1.44 |
- |
- |
- |
34.6 |
500 |
|
18 |
41/0.16 |
1.18 |
0.25 |
1.68 |
- |
- |
- |
21.8 |
500 |
|
16 |
26/0.254 |
1.49 |
0.25 |
2.06 |
- |
- |
- |
13.7 |
500 |
