Complies with UL standards: UL758, UL1581, and CSA, C22.2, No. 210.2
30V
| conductor | insulation | shield | outer sheath | Maximum conductor resistance（Q/m，20°C，DC） | Compressive strength（VAC，1min） | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Line gauge（AWG） | structure(No./mm) | outer diameter（mm） | Chip count | nominal thickness（mm） | outer diameter（mm） | crossbody bag | Drainage line | Weaving | nominal thickness(mm) | outer diameter(mm) | ||
|
30 |
7/0.10 |
0.30 |
10P |
0.05 |
0.60 |
Al-mylar |
7/0.10 |
16/8/0.10 |
0.51 |
5.40 |
381 |
500 |
|
30 |
7/0.10 |
0.30 |
15P |
0.05 |
0.60 |
Al-mylar |
7/0.10 |
24/6/0.10 |
0.51 |
6.20 |
381 |
500 |
|
30 |
7/0.10 |
0.30 |
18P |
0.05 |
0.60 |
Al-mylar |
7/0.10 |
24/7/0.10 |
0.51 |
6.70 |
381 |
500 |
|
30 |
7/0.10 |
0.30 |
19P |
0.05 |
0.60 |
Al-mylar |
7/0.10 |
24/7/0.10 |
0.51 |
6.90 |
381 |
500 |
|
30 |
7/0.10 |
0.30 |
25P |
0.05 |
0.60 |
Al-mylar |
7/0.10 |
24/8/0.10 |
0.51 |
7.70 |
381 |
500 |
|
28 |
7/0.12 |
0.38 |
10P |
0.05 |
0.70 |
Al-mylar |
7/0.127 |
16/6/0.10 |
0.51 |
6.00 |
239 |
500 |
|
28 |
7/0.12 |
0.38 |
15P |
0.05 |
0.70 |
Al-mylar |
7/0.127 |
24/5/0.10 |
0.51 |
7.10 |
239 |
500 |
|
28 |
7/0.12 |
0.38 |
18P |
0.05 |
0.70 |
Al-mylar |
7/0.127 |
24/8/0.10 |
0.51 |
7.60 |
239 |
500 |
|
28 |
7/0.12 |
0.38 |
19P |
0.05 |
0.70 |
Al-mylar |
7/0.127 |
24/8/0.10 |
0.51 |
7.80 |
239 |
500 |
|
28 |
7/0.12 |
0.38 |
25P |
0.05 |
0.70 |
Al-mylar |
7/0.127 |
24/9/0.10 |
0.51 |
8.80 |
239 |
500 |
|
26 |
7/0.16 |
0.48 |
3P |
0.05 |
0.80 |
Al-mylar |
7/0.16 |
16/6/0.10 |
0.51 |
4.40 |
150 |
500 |
|
26 |
7/0.16 |
0.48 |
6P |
0.05 |
0.80 |
Al-mylar |
7/0.16 |
24/6/0.10 |
0.51 |
5.50 |
150 |
500 |
|
26 |
7/0.16 |
0.48 |
9P |
0.05 |
0.80 |
Al-mylar |
7/0.16 |
24/7/0.10 |
0.51 |
6.40 |
150 |
500 |
