30V
| conductor | insulation | shield | outer sheath | Maximum conductor resistance（Q/m，20°C，DC） | Compressive strength（VAC，1min） | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Line gauge（AWG） | structure(No./mm) | outer diameter（mm） | Chip count | nominal thickness（mm） | outer diameter（mm） | crossbody bag | Drainage line | Weaving | nominal thickness(mm) | outer diameter(mm) | ||
|
30 |
7/0.10 |
0.30 |
2 |
0.05 |
0.80 |
Al-mylar |
7/0.10 |
16/4/0.10 |
0.38 |
3.30 |
381 |
500 |
|
30 |
7/0.10 |
0.30 |
3 |
0.05 |
0.80 |
Al-mylar |
7/0.10 |
16/4/0.10 |
0.38 |
3.50 |
381 |
500 |
|
30 |
7/0.10 |
0.30 |
4 |
0.05 |
0.80 |
Al-mylar |
7/0.10 |
16/5/0.10 |
0.38 |
3.60 |
381 |
500 |
|
30 |
7/0.10 |
0.30 |
5 |
0.05 |
0.80 |
Al-mylar |
7/0.10 |
16/5/0.10 |
0.38 |
4.00 |
381 |
500 |
|
30 |
7/0.10 |
0.30 |
6 |
0.05 |
0.80 |
Al-mylar |
7/0.10 |
16/6/0.10 |
0.38 |
4.20 |
381 |
500 |
|
30 |
7/0.10 |
0.30 |
7 |
0.05 |
0.80 |
Al-mylar |
7/0.10 |
16/6/0.10 |
0.38 |
4.20 |
381 |
500 |
|
30 |
7/0.10 |
0.30 |
8 |
0.05 |
0.80 |
Al-mylar |
7/0.10 |
16/7/0.10 |
0.38 |
4.50 |
381 |
500 |
|
30 |
7/0.10 |
0.30 |
9 |
0.05 |
0.80 |
Al-mylar |
7/0.10 |
16/7/0.10 |
0.38 |
4.80 |
381 |
500 |
|
30 |
7/0.10 |
0.30 |
10 |
0.05 |
0.80 |
Al-mylar |
7/0.10 |
16/7/0.10 |
0.38 |
5.00 |
381 |
500 |
|
28 |
7/0.127 |
0.38 |
2 |
0.05 |
0.90 |
Al-mylar |
7/0.127 |
16/5/0.10 |
0.38 |
3.50 |
239 |
500 |
|
28 |
7/0.127 |
0.38 |
3 |
0.05 |
0.90 |
Al-mylar |
7/0.127 |
16/5/0.10 |
0.38 |
3.70 |
239 |
500 |
|
28 |
7/0.127 |
0.38 |
4 |
0.05 |
0.90 |
Al-mylar |
7/0.127 |
16/6/0.10 |
0.38 |
4.00 |
239 |
500 |
|
28 |
7/0.127 |
0.38 |
5 |
0.05 |
0.90 |
Al-mylar |
7/0.127 |
16/6/0.10 |
0.38 |
4.20 |
239 |
500 |
|
28 |
7/0.127 |
0.38 |
6 |
0.05 |
0.90 |
Al-mylar |
7/0.127 |
16/6/0.10 |
0.38 |
4.50 |
239 |
500 |
|
28 |
7/0.127 |
0.38 |
7 |
0.05 |
0.90 |
Al-mylar |
7/0.127 |
16/6/0.10 |
0.38 |
4.50 |
239 |
500 |
|
28 |
7/0.127 |
0.38 |
8 |
0.05 |
0.90 |
Al-mylar |
7/0.127 |
16/7/0.10 |
0.38 |
4.80 |
239 |
500 |
|
28 |
7/0.127 |
0.38 |
9 |
0.05 |
0.90 |
Al-mylar |
7/0.127 |
16/8/0.10 |
0.38 |
5.20 |
239 |
500 |
|
28 |
7/0.127 |
0.38 |
10 |
0.05 |
0.90 |
Al-mylar |
7/0.127 |
16/8/0.10 |
0.38 |
5.50 |
239 |
500 |
|
26 |
7/0.16 |
0.48 |
2 |
0.05 |
1.00 |
Al-mylar |
7/0.16 |
16/5/0.10 |
0.38 |
3.70 |
150 |
500 |
|
26 |
7/0.16 |
0.48 |
3 |
0.05 |
1.00 |
Al-mylar |
7/0.16 |
16/5/0.10 |
0.38 |
3.90 |
150 |
500 |
|
26 |
7/0.16 |
0.48 |
4 |
0.05 |
1.00 |
Al-mylar |
7/0.16 |
16/6/0.10 |
0.38 |
4.20 |
150 |
500 |
|
26 |
7/0.16 |
0.48 |
5 |
0.05 |
1.00 |
Al-mylar |
7/0.16 |
16/6/0.10 |
0.38 |
4.50 |
150 |
500 |
|
26 |
7/0.16 |
0.48 |
6 |
0.05 |
1.00 |
Al-mylar |
7/0.16 |
16/7/0.10 |
0.38 |
4.80 |
150 |
500 |
|
26 |
7/0.16 |
0.48 |
7 |
0.05 |
1.00 |
Al-mylar |
7/0.16 |
16/7/0.10 |
0.38 |
4.80 |
150 |
500 |
|
26 |
7/0.16 |
0.48 |
8 |
0.05 |
1.00 |
Al-mylar |
7/0.16 |
16/7/0.10 |
0.38 |
5.20 |
150 |
500 |
|
26 |
7/0.16 |
0.48 |
9 |
0.05 |
1.00 |
Al-mylar |
7/0.16 |
16/8/0.10 |
0.38 |
5.60 |
150 |
500 |
|
26 |
7/0.16 |
0.48 |
10 |
0.05 |
1.00 |
Al-mylar |
7/0.16 |
16/8/0.10 |
0.38 |
5.90 |
150 |
500 |
|
24 |
11/0.16 |
0.61 |
2 |
0.05 |
2.20 |
Al-mylar |
11/0.16 |
16/5/0.10 |
0.38 |
3.90 |
94.2 |
500 |
|
24 |
11/0.16 |
0.61 |
3 |
0.05 |
2.20 |
Al-mylar |
11/0.16 |
16/5/0.10 |
0.38 |
4.10 |
94.2 |
500 |
|
24 |
11/0.16 |
0.61 |
4 |
0.05 |
2.20 |
Al-mylar |
11/0.16 |
16/6/0.10 |
0.38 |
4.40 |
94.2 |
500 |
|
24 |
11/0.16 |
0.61 |
5 |
0.05 |
2.20 |
Al-mylar |
11/0.16 |
16/6/0.10 |
0.38 |
4.80 |
94.2 |
500 |
|
24 |
11/0.16 |
0.61 |
6 |
0.05 |
2.20 |
Al-mylar |
11/0.16 |
16/7/0.10 |
0.38 |
5.20 |
94.2 |
500 |
|
24 |
11/0.16 |
0.61 |
7 |
0.05 |
2.20 |
Al-mylar |
11/0.16 |
16/7/0.10 |
0.38 |
5.20 |
94.2 |
500 |
|
24 |
11/0.16 |
0.61 |
8 |
0.05 |
2.20 |
Al-mylar |
11/0.16 |
16/7/0.10 |
0.38 |
5.40 |
94.2 |
500 |
|
24 |
11/0.16 |
0.61 |
9 |
0.05 |
2.20 |
Al-mylar |
11/0.16 |
16/8/0.10 |
0.38 |
5.90 |
94.2 |
500 |
|
24 |
11/0.16 |
0.61 |
10 |
0.05 |
2.20 |
Al-mylar |
11/0.16 |
16/8/0.10 |
0.38 |
6.30 |
94.2 |
500 |
|
22 |
17/0.16 |
0.76 |
2 |
0.05 |
2.35 |
Al-mylar |
17/0.16 |
16/6/0.10 |
0.38 |
4.30 |
59.4 |
500 |
|
22 |
17/0.16 |
0.76 |
3 |
0.05 |
2.35 |
Al-mylar |
17/0.16 |
16/6/0.10 |
0.38 |
4.50 |
59.4 |
500 |
|
22 |
17/0.16 |
0.76 |
4 |
0.05 |
2.35 |
Al-mylar |
17/0.16 |
16/7/0.10 |
0.38 |
4.90 |
59.4 |
500 |
|
22 |
17/0.16 |
0.76 |
5 |
0.05 |
2.35 |
Al-mylar |
17/0.16 |
16/8/0.10 |
0.38 |
5.40 |
59.4 |
500 |
|
22 |
17/0.16 |
0.76 |
6 |
0.05 |
2.35 |
Al-mylar |
17/0.16 |
16/8/0.10 |
0.38 |
5.80 |
59.4 |
500 |
|
22 |
17/0.16 |
0.76 |
7 |
0.05 |
2.35 |
Al-mylar |
17/0.16 |
16/8/0.10 |
0.38 |
5.80 |
59.4 |
500 |
|
22 |
17/0.16 |
0.76 |
8 |
0.05 |
2.35 |
Al-mylar |
17/0.16 |
16/8/0.10 |
0.38 |
6.10 |
59.4 |
500 |
|
22 |
17/0.16 |
0.76 |
9 |
0.05 |
2.35 |
Al-mylar |
17/0.16 |
16/9/0.10 |
0.76 |
7.00 |
59.4 |
500 |
|
22 |
17/0.16 |
0.76 |
10 |
0.05 |
2.35 |
Al-mylar |
17/0.16 |
16/10/0.1 |
0.76 |
7.30 |
59.4 |
500 |
|
20 |
26/0.16 |
0.94 |
2 |
0.05 |
2.50 |
Al-mylar |
26/0.16 |
16/7/0.10 |
0.38 |
4.70 |
36.7 |
500 |
|
20 |
26/0.16 |
0.94 |
3 |
0.05 |
2.50 |
Al-mylar |
26/0.16 |
16/7/0.10 |
0.38 |
5.00 |
36.7 |
500 |
|
20 |
26/0.16 |
0.94 |
4 |
0.05 |
2.50 |
Al-mylar |
26/0.16 |
16/8/0.10 |
0.38 |
5.40 |
36.7 |
500 |
|
20 |
26/0.16 |
0.94 |
5 |
0.05 |
2.50 |
Al-mylar |
26/0.16 |
16/8/0.10 |
0.38 |
5.90 |
36.7 |
500 |
|
20 |
26/0.16 |
0.94 |
6 |
0.05 |
2.50 |
Al-mylar |
26/0.16 |
16/9/0.10 |
0.76 |
6.60 |
36.7 |
500 |
|
20 |
26/0.16 |
0.94 |
7 |
0.05 |
2.50 |
Al-mylar |
26/0.16 |
16/9/0.10 |
0.76 |
6.60 |
36.7 |
500 |
|
20 |
26/0.16 |
0.94 |
8 |
0.05 |
2.50 |
Al-mylar |
26/0.16 |
16/9/0.10 |
0.76 |
7.10 |
36.7 |
500 |
|
20 |
26/0.16 |
0.94 |
9 |
0.05 |
2.50 |
Al-mylar |
26/0.16 |
16/9/0.12 |
0.76 |
7.80 |
36.7 |
500 |
|
20 |
26/0.16 |
0.94 |
10 |
0.05 |
2.50 |
Al-mylar |
26/0.16 |
16/9/0.12 |
0.76 |
8.20 |
36.7 |
500 |
|
18 |
41/0.16 |
1.18 |
2 |
0.05 |
2.75 |
Al-mylar |
41/0.16 |
16/8/0.10 |
0.38 |
5.30 |
23.2 |
500 |
|
18 |
41/0.16 |
1.18 |
3 |
0.05 |
2.75 |
Al-mylar |
41/0.16 |
16/8/0.10 |
0.38 |
5.70 |
23.2 |
500 |
|
18 |
41/0.16 |
1.18 |
4 |
0.05 |
2.75 |
Al-mylar |
41/0.16 |
16/8/0.10 |
0.38 |
6.20 |
23.2 |
500 |
|
18 |
41/0.16 |
1.18 |
5 |
0.05 |
2.75 |
Al-mylar |
41/0.16 |
16/9/0.10 |
0.76 |
7.10 |
23.2 |
500 |
|
18 |
41/0.16 |
1.18 |
6 |
0.05 |
2.75 |
Al-mylar |
41/0.16 |
16/9/0.10 |
0.76 |
7.60 |
23.2 |
500 |
|
18 |
41/0.16 |
1.18 |
7 |
0.05 |
2.75 |
Al-mylar |
41/0.16 |
16/9/0.10 |
0.76 |
7.60 |
23.2 |
500 |
|
18 |
41/0.16 |
1.18 |
8 |
0.05 |
2.75 |
Al-mylar |
41/0.16 |
16/9/0.12 |
0.76 |
8.20 |
23.2 |
500 |
|
18 |
41/0.16 |
1.18 |
9 |
0.05 |
2.75 |
Al-mylar |
41/0.16 |
16/9/0.12 |
0.76 |
8.90 |
23.2 |
500 |
|
18 |
41/0.16 |
1.18 |
10 |
0.05 |
2.75 |
Al-mylar |
41/0.16 |
16/10/0.1 |
0.76 |
9.50 |
23.2 |
500 |
