Rated voltage
U0/U 300/500V
U0/U 300/500V
Fixed installation: 6D (cable outer diameter)
Mobile installation: 13D (cable outer diameter)
Meets ASTM standards
Passed GB/T2951.5 test
Fixed installation: -10℃ ~ +70℃
Mobile installation: -5℃ ~ +70℃
Passed IEC 60332.1 test
Oil resistance, cold resistance, acid and alkali resistance, solvent resistance, etc. (optional)
Cable data
|
Product Code |
Cross section (mm2) |
Chip count |
Approximate outer diameter (mm) |
Approximate weight (kg/km) |
|
J0335102012041406BK |
0.5 |
2 |
7.8±0.4 |
86.14 |
|
J0335102014041406BK |
1 |
2 |
8.8±0.6 |
113.73 |
|
J0335103012041406BK |
0.5 |
3 |
8.3±0.6 |
100.87 |
|
J0335103014041406BK |
1 |
3 |
9.2±0.6 |
130.88 |
|
J0335104012041406BK |
0.5 |
4 |
8.9±0.6 |
115.35 |
|
J0335104014041406BK |
1 |
4 |
10±0.6 |
156.79 |
|
J0335105012041406BK |
0.5 |
5 |
9.5±0.6 |
130.66 |
|
J0335105014041406BK |
1 |
5 |
10.8±0.6 |
184.27 |
|
J0335106012041406BK |
0.5 |
6 |
10.3±0.6 |
151.05 |
|
J0335106014041406BK |
1 |
6 |
12±0.6 |
219.09 |
|
J0335107012041406BK |
0.5 |
7 |
10.3±0.6 |
151.05 |
|
J0335107014041406BK |
1 |
7 |
12±0.6 |
219.09 |
|
J0335108012041406BK |
0.5 |
8 |
11.4±0.6 |
182.51 |
|
J0335109012041406BK |
0.5 |
9 |
12.3±0.6 |
202.98 |
|
J0335110012041406BK |
0.5 |
10 |
13±0.6 |
231.29 |
|
J0335111012041406BK |
0.5 |
11 |
13.3±0.6 |
245.49 |
|
J0335112012041406BK |
0.5 |
12 |
13.3±0.6 |
251.75 |
|
J0335113012041406BK |
0.5 |
13 |
14.1 ±0.8 |
276.07 |
|
J0335114012041406BK |
0.5 |
14 |
14.1 ±0.8 |
282.33 |
|
J0335115012041406BK |
0.5 |
15 |
14.7±0.8 |
301.47 |
|
J0335116013041406BK |
0.75 |
16 |
15.9±0.8 |
384.14 |
|
J0335117013041406BK |
0.75 |
17 |
16.6±0.8 |
408.78 |
|
J0335118013041406BK |
0.75 |
18 |
16.6±0.8 |
417.51 |
|
J0335119013041406BK |
0.75 |
19 |
16.6±0.8 |
417.51 |
|
J0335120013041406BK |
0.75 |
20 |
17.1 ±0.8 |
440.65 |
|
J0335121013041406BK |
0.75 |
21 |
17.7±0.8 |
467.19 |
|
J0335122013041406BK |
0.75 |
22 |
18.8±0.8 |
505.48 |
|
J0335123013041406BK |
0.75 |
23 |
19.6±0.8 |
555.85 |
|
J0335124013041406BK |
0.75 |
24 |
19.6±0.8 |
564.58 |
|
J0335125013041406BK |
0.75 |
25 |
20.2±1 |
592.78 |
|
J0335126013041406BK |
0.75 |
26 |
20.2±1 |
604.48 |
|
J0335127013041406BK |
0.75 |
27 |
20.2±1 |
613.21 |
|
J0335112012041406BK |
0.5 |
12 |
13.3±0.6 |
251.75 |
|
J0335113012041406BK |
0.5 |
13 |
14.1 ±0.8 |
276.07 |
|
J0335114012041406BK |
0.5 |
14 |
14.1 ±0.8 |
282.33 |
|
J0335115012041406BK |
0.5 |
15 |
14.7±0.8 |
301.47 |
|
J0335116013041406BK |
0.75 |
16 |
15.9±0.8 |
384.14 |
|
J0335117013041406BK |
0.75 |
17 |
16.6±0.8 |
408.78 |
|
J0335118013041406BK |
0.75 |
18 |
16.6±0.8 |
417.51 |
|
J0335119013041406BK |
0.75 |
19 |
16.6±0.8 |
417.51 |
|
J0335120013041406BK |
0.75 |
20 |
17.1 ±0.8 |
440.65 |
|
J0335121013041406BK |
0.75 |
21 |
17.7±0.8 |
467.19 |
|
J0335122013041406BK |
0.75 |
22 |
18.8±0.8 |
505.48 |
|
J0335123013041406BK |
0.75 |
23 |
19.6±0.8 |
555.85 |
|
J0335124013041406BK |
0.75 |
24 |
19.6±0.8 |
564.58 |
|
J0335125013041406BK |
0.75 |
25 |
20.2±1 |
592.78 |
|
J0335126013041406BK |
0.75 |
26 |
20.2±1 |
604.48 |
|
J0335127013041406BK |
0.75 |
27 |
20.2±1 |
613.21 |
|
J0335133013041406BK |
0.75 |
33 |
21.6±1 |
714 |
|
J0335134013041406BK |
0.75 |
34 |
22.3±1 |
740.69 |
|
J0335135013041406BK |
0.75 |
35 |
22.3±1 |
752.4 |
|
J0335136013041406BK |
0.75 |
36 |
22.3±1 |
761.13 |
|
J0335137013041406BK |
0.75 |
37 |
22.3±1 |
761.13 |
